Manxing provides durable flat bottom steel silos designed for large-capacity grain storage. Our silos feature 275g/m² galvanized steel sheets, long lifespan, and automated unloading systems. Perfect for storing wheat, corn, rice, soybeans, and feed.

Get A Free Quote

Home > Products

Flat Bottom Steel Silo

Name: Flat Bottom Silo for Grain Storage | Steel Grain Silo Manufacturer…
Brand: ManXing Machinery | Grain Storage Silos & Complete Silo Systems
SKU: mx-1

Quote Now

Send E-mail

Introduction

Download

Case

Related Products

Send Inquiry

Introduction

Flat Bottom Steel Silo

The Flat Bottom Silo from Manxing Machinery is specially engineered for long-term bulk grain storage applications.

Built with 275g/m² hot-dip galvanized steel sheets, our silos deliver exceptional corrosion resistance and a service life exceeding 30 years.

The flat bottom structure allows for large storage capacity, ranging from 500 to 10,000 tons, and is compatible with aeration, temperature control, and automatic unloading systems to maintain grain quality.

Each silo is equipped with:

Strong corrugated steel walls for durability and wind resistance
Advanced sealing design to prevent moisture and pests
Optional ventilation and temperature monitoring systems
Customized unloading systems for easy grain discharge

Grain Silo Capacity Calculation:

Diameter (m)	No. of Rings	Eave Height (m)	Overall Height (m)	Capacity (m³)	Capacity (Ton)
Diameter (m)	No. of Rings	Eave Height (m)	Overall Height (m)	Capacity (m³)	Wheat (0.770 m³/t)	Maize (0.721 m³/t)	Paddy (0.640 m³/t)
4.57	8~20	6.58~16.37	7.72~17.52	114~275	93~224	87~210	78~186
5.48	8~20	6.58~16.37	7.99~17.78	167~398	136~325	127~304	113~270
6.40	8~24	6.578~19.63	8.25~21.31	229~649	187~530	175~496	156~440
7.31	8~26	6.58~21.27	8.51~23.20	303~919	247~750	232~703	206~624
8.22	8~30	6.578~24.53	8.66~26.61	388~1341	317~1095	296~1025	263~910
9.14	8~32	6.58~26.16	8.93~28.51	484~1768	395~1443	370~1351	328~1199
10.05	8~32	6.58~26.16	9.19~28.77	592~2146	483~1751	453~1640	402~1456
10.96	8~32	6.58~26.16	9.45~29.04	713~2561	582~2090	545~1957	483~1737
11.88	8~32	6.58~26.16	9.72~29.30	845~3015	690~2461	646~2304	573~2045
12.79	8~32	6.58~26.16	9.98~29.57	991~3507	809~2862	757~2680	672~2379
14.62	8~32	6.58~26.16	10.28~29.86	1321~4607	1078~3760	1009~3521	896~3125
15.53	8~34	6.58~27.79	10.54~31.76	1506~5525	1229~4510	1151~4223	1022~3748
16.44	8~36	6.58~29.43	10.81~33.65	1706~6558	1392~5353	1304~5012	1157~4449
18.27	8~36	6.58~29.43	11.33~34.18	2149~8139	1754~6643	1642~6221	1458~5522
20.10	8~36	6.58~29.43	11.86~34.71	2651~9900	2164~8081	2026~7566	1799~6716
21.93	8~36	6.58~29.43	12.39~35.24	3217~11843	2625~9666	2458~9051	2182~8034
22.84	8~36	6.58~29.43	12.48~35.33	3523~12883	2875~10515	2692~9846	2390~8740
23.75	8~36	6.58~29.43	12.74~35.59	3846~13971	3139~11403	2940~10677	2609~9478
25.58	8~36	6.58~29.43	13.27~36.12	4544~16286	3709~13293	3473~12447	3083~11048
27.41	8~36	6.58~29.43	13.62~36.47	5311~18790	4335~15337	4059~14361	3603~12747
30.15	8~34	6.58~27.79	14.42~35.63	6600~21745	5387~17748	5044~16619	4478~14752
31.98	8~34	6.58~27.79	14.94~36.16	7555~24591	6166~20071	5774~18794	5125~16682

Manxing’s flat bottom silos are widely used in grain depots, feed mills, ports, and agricultural projects worldwide.

Choose Manxing for a professional grain storage solution with high efficiency, durability, and low maintenance cost.

PDF

Product File

Manxing Silo Brochure

Manxing_Silo_Brochure.pdf

Open the download form to unlock this file. The source page is recorded automatically in your customer submissions.

Case

Steel Silo Case Studies | Grain, Cement & Bulk Material Storage Projects | Manxing

Discover Manxing’s comprehensive steel silo case studies, showcasing successful projects worldwide, including grain silos, cement silos, flour silos, and mineral powder storage systems. Our turnkey solutions feature high-quality materials, efficient on-site construction, and customized designs to meet diverse industrial storage needs. See how Manxing delivers reliable, durable, and scalable silo installations for clients across agriculture, construction, and manufacturing sectors.

Philippines 2×60-Ton Rice Silo Export & Installation Support Project

This case study details a Philippine 2×60-ton rice steel silo export project—from customized design and precision manufacturing to shipping and on-site engineer dispatch for installation supervision, delivering a complete turnkey grain storage solution.

East Africa Grain Drying Project Case

Complete maize drying and storage solutions for East Africa. See how Manxing helped grain collectors and processors in Tanzania, Kenya, and Uganda with continuous dryers, silos, and automated systems.

6×5000Ton Grain Storage for Grain Traders in Nigeria

A regional grain trading company sought to modernize its grain storage infrastructure to support increasing procurement volumes during harvest seasons and improve the efficiency of grain distribution throughout the year. As the company supplied grain to f

3×2000Ton Storage System for Rice Mill Plant in Bolivia

Manxing delivered a complete storage system tailored to the customer's production process, providing engineering design, equipment manufacturing, installation guidance, and commissioning services as part of a turnkey EPC solution.

The 5x2000T Grain Silos Project in Philippines

Project Advantages: Turnkey solution from design to installation Rich experience in international grain silo projects Custom engineering tailored to local climate conditions Reliable quality with competitive pricing Professional after-sales support

2000-ton Grain Silo Project for Feed Mill in Vietnam

In 2024, Manxing supplied a grain storage system for a feed processing company in Vietnam. The customer operates a medium-sized feed mill that produces poultry and livestock feed for regional farms.
